| Microscope |
|
| Type |
Galileo magnification changer with converging |
| Model of Magnifying |
5 steps by drum rotation |
| Eyepiece |
12.5 x |
| Total Magnification Rate |
6x 10x 16x 25x 40x |
| (Field-of-view) |
(→33mm) (→22.5mm) (→14mm) (→8.8mm) (→5.5mm) |
| Range of P. D. Adjustment |
55mm to 75mm |
| Diopter Adjustment |
-5D to +3D |
| Illumination |
|
| Slit Projection Magnification |
1.16x |
| Slit Width |
Continuous from 0mm to 14mm(become a circle at 14mm) |
| Slit Height |
Continuous from 1mm to 14mm |
| Aperture Diameter |
14mm, 9mm, 5.5mm, 0.3mm |
| Slit Angle |
0°to 180°continuously adjustable from vertical to horizontal |
| Filter Piece |
Heat-absorbing, red-free, blue |
| Illumination Bulb |
6V20W halogen bulb |
| Movement Base |
|
| Fore and Back Movement |
90mm |
| Left and Right Movement |
100mm |
| Fine Movement |
15mm |
| Vertical Movement |
30mm |
| Chin-rest Parts |
80mm |
| Vertical Movement |
|
| Fixation Target |
Red LED |
| Power Source |
|
| Input Voltage |
AC110V/220V±←10％ |
| Input Frequency |
50/60Hz |
| Input Power |
30VA |
| Output Voltage |
Illumination bulb 4V, 5V, 6V |
| |
Fixation target 6V |
| Electric Safe Standard |
Conform to Standard IEC601 -1, Class I Type B |
| Dimension and Weight |
|
| Packing Box |
720mm x 495mm x 480mm |
| Total Weight |
23 Kg |
| Net Weight |
17 Kg |
